Product Details:
|
| Main Raw Materials: | Acrylic Resin,Polyurethane Resin | Feature: | High Leveling,high Glossy,high Fullness,good Covering,high Adhesion |
|---|---|---|---|
| Color: | Transparent,transparent With Light Yellow | Substrate: | 1k Base Coat |
| Effect: | Fast Drying ,slow Drying ,standard Speed Drying | Component Style: | Bi-component |
| High Light: | Yellow Resistant Auto Clear Coat,High Transparent Auto Clear Coat,High Solid Car Paint Scratch Resistant |
||
High Transparent Yellow Resistant Auto Clear Coat High Solid For Car
Product Description:
Clear coat
- According to the structure, car varnishes are divided into two-component high solids (HS) and medium solids (MS), as well as fluid (aerosol) varnish. Two-component varnish (HS) is a “solid” mixture consisting of volatile and non-volatile substances. The percentage of components is as follows: from 50 to 70% – varnish itself; from 20 to 40% – hardener; 10-15% – solvent. Two-component MS varnish is a substance of medium hardness. The composition has a higher proportion of solvent (30-50%) and a smaller amount of varnish itself (35-45%). It’s characterized by fast drying and highly resistant to scratching. It is necessary to apply such varnish in at least two layers.
Physical properties
| Product introduction | Two-component clear coat, cost-effective, resistant to various chemical erosion, durable weather resistance and good gloss retention. |
| Density | 0.93 kg/L |
| Raw materials | Acrylic Resin, Additive, Solvent |
| Colors | Transparent |
| Solid content | 52%,53%,55%,60% |
Product List
| Item No. | Product Name | Mixning ratio: (base paint : hardener : thinner) |
volume of package can |
| ES7600 | UV Resistance Super Fast Dry Clear Coat | 1 : 0.5:(0.2-0.3) | 1L,4L,20L |
| ES840 | matte clear coat | 1 : 0.5:(0.2-0.3) | 1L,4L,20L |
| ES850 | 4:1 HS UV Resistance Clear Coat | 1 : 0.5:(0.2-0.3) | 1L,4L,20L |
| ES810 | MS Clear Coat | 1 : 0.5:(0.2-0.3) | 1L,4L,20L |
| ES810-1 | MS Clear Coat | 1 : 0.5:(0.2-0.3) | 1L,4L,20L |
| ES830 | MS Clear Coat High Gloss | 1 : 0.5:(0.2-0.3) | 1L,4L,20L |
| ES870 | VOC Clear Coat | 1 : 0.5:(0.2-0.3) | 1L,4L,20L |
| ES950 | HS Clear Coat (UV resistant) | 1 : 0.5:(0.2-0.3) | 1L,4L,20L |
| ES980 | HS extra Clear Coat (UV resistant) | 1 : 0.5:(0.2-0.3) | 1L,4L,20L |
| ES9600 | clear coat | 1 : 0.5:(0.2-0.3) | 1L,4L,20L |
| ES999-1 | HS EXTRA UV resistant clear coat | 1 : 0.5:(0.2-0.3) | 1L,4L,20L |
| ES999 | E-HS EXTRA UV resistant clear coat | 1 : 0.5:(0.2-0.3) | 1L,4L,20L |
Note:
-Be careful not to introduce air bubbles
-When applying the top coat, be sure to check the dilution before use.
Application process:
| spray gun | Gravity gun | Suction gun |
| gun nozzle: 1.3-1.5mm, gun pressure: 2.0-4.0 MPa |
gun nozzle: 1.3-1.5mm, gun pressure: 1.5 - 2.0 Mpa |
|
| substrate | dry 1K base coat /dry clear coat | |
| Paint preparation | clear coat, hardener: denpents on what model no.of thinner: EX10/EX20/EX30 |
|
| mix ratio | 1 : 0.5:(0.2-0.3) (base paint : hardener : thinner) | |
| spraying layers | 2-3 coats | |
| flash off time | 5-10 mins , 20-25℃ | |
| surface dry time | 20mins | |
| Time to Polish | 8hours | |
| Relationship between drying temperature and time of clear coat | ||
| Tenmperture | Surface Drying time | Time to Polish |
| 25℃ | 20 mins | 8 hours |
| 60℃ | 10 mins | 2 hours |
| infrared light | 5 mins | 1 hour |
Storage :
Keep in a tightly covered container and in a dry and ventilated environment,avoiding exposure in sun directly.Temperature above 10℃ is recommended,between 15 and 30 ℃ optimal.
Optional Thinner for the clear coat
| Item | Product name | Density | mixing ratio (2k coat : hardener:thinner) |
| EX10 | High Quality Fast Thinner | 0.85 | 1 :0.5: (0.2-0.3) |
| EX20 | High Quality Standard Thinner | 0.85 | 1 :0.5: (0.2-0.3) |
| EX30 | High Quality Slow Thinner | 0.85 | 1 :0.5: (0.2-0.3) |
| EX50 | High Quality Extra Slow Thinner | 0.85 | 1 :0.5: (0.2-0.3) |
| D5 | Extra Slow Thinner | 0.85 | 1 :0.5: (0.2-0.3) |
| D3 | Fast Thinner | 0.85 | 1 :0.5: (0.2-0.3) |
| D2 | Standard Thinner | 0.85 | 1 :0.5: (0.2-0.3) |
| D1 | Slow Thinner | 0.85 | 1 :0.5: (0.2-0.3) |
Optional hardener for the clear coat
| Item | Product name | Density | mixing ratio (clear coat : hardener:thinner) |
| EC21 | Fast Drying Hardener to ES810 | 0.93 | 1 :0.5: (0.2-0.3) |
| EC22 | Standard Drying Hardener to ES810 | 0.93 | 1 :0.5: (0.2-0.3) |
| EC23 | Slow Drying Hardener to ES810 | 0.93 | 1 :0.5: (0.2-0.3) |
| EC25 | Fast Drying Hardener to ES830 | 0.93 | 1 :0.5: (0.2-0.3) |
| EC26 | Standard Drying Hardener to ES830 | 0.93 | 1 :0.5: (0.2-0.3) |
| EC27 | Slow Drying Hardener to ES830 | 0.93 | 1 :0.5: (0.2-0.3) |
| EC38 | 4:1 HS Hardener | 0.93 | 1 :0.5: (0.2-0.3) |
| EC31 | Fast Drying Hardener to ES950/ES980 | 0.93 | 1 :0.5: (0.2-0.3) |
| EC32 | Standard Drying Hardener to ES950/ES980 | 0.93 | 1 :0.5: (0.2-0.3) |
| EC33 | Slow Drying Hardener to ES950/ES980 | 0.93 | 1 :0.5: (0.2-0.3) |
| EC60 | 4:1 Hardener to ES850 | 0.93 | 1 :0.5: (0.2-0.3) |
| EC908 | Fast Drying Hardener to ES999 | 0.93 | 1 :0.5: (0.2-0.3) |
| EC907 | Standard Drying Hardener to ES999 | 0.93 | 1 :0.5: (0.2-0.3) |
| EC906 | Slow Drying Hardener to ES999 | 0.93 | 1 :0.5: (0.2-0.3) |
| EC909 | Fast dry hardener(EC909) | 0.93 | 1 :0.5: (0.2-0.3) |
| EC300 | General hardener | 0.93 | 1 :0.5: (0.2-0.3) |
| EC333 | HS Hardener(to ES7000/8000 Clear Coat) | 0.93 | 1 :0.5: (0.2-0.3) |
Additive details:
| Item No. | Product Name | Feature | Funtion |
| 123 | Degreaser | Volatile transparent liquid | ①It is used to clean up the surface of metal. ②Dust removal, oil removal and anti-static resistance |
| 124 | Raccord Thinner | Transparent colorless liquid | Dissolve the interface position of the old and new paint, so that the old and new paint films are integrated, and the repair effect is more perfect. |
| 103 | Drying Additive | Volatile transparent liquid with light Yellow | If the ambient humidity is high, add 1% (based on weight) to make the main paint reach the normal drying time. |
| 120 | Retarder | Transparent colorless liquid | ①The addition amount is generally 10% of the total amount of paint. ②It can delay the drying speed of the paint surface. It is a slow drying diluent |
| PS: The additives above do not have to be uesd with the paint ,it should according to climate situation of the using region. | |||
